AMPLIFIER
Amplifier chuyên khuếch đại tín hiệu âm thanh phát ra bằng loa cực mạnh.
Infinity Kappa Amplifier One K
AMP002
Features
Class D Design
Low Distortion
Full On-Board Protection
Proprietary High-Conductivity Terminals
Compact footprint
Sleek design
DBO™ (Dynamic Bass Optimizer)
Remote Bass Control
What’s in the Box
1x Amplifier
2x Differential Speaker-Level Adapter
3x Spare Fuses
4x Philip Screws
1x Remote Bass Control & Cable
1x E.A.R.L Terminal
3x Self-Tapping Screws
1x Power Terminal Block
1x Owner’s Manual
Technical Specifications:
Operating voltage 9 – 16 volts
RMS power @ 4 ohms 700W
RMS power @ 2 ohms 1000W
Total peak power 2600W
Frequency response 10Hz – 320Hz @ -3dB
Crossover filter LPF 32Hz – 320Hz Variable
12dB/Oct
Bass EQ 10Hz – 80Hz variable 0 – 12dB
THD + N at rated power ≤0.1%
High input maximum signal level 20V
High input maximum sensitivity 2V
Line input maximum signal level 2V
Line input maximum sensitivity 0.2V
Line-in signal-to-noise ratio
(reference to 1 watt) ≥80dB
Quiescent current draw ≤2A
Fuse size 3 x 35A
Dimensions (H x W x D) 43 x 177 x 335mm
Weight 3.4kg
JBL Amplifiers GTR-102
GTR-102
Product specifications:
GTR-102
High Performance 2-Channel Full Range Car Audio Power Amplifier
Max Power: 700W Peak
Power Output, 4Ω: 100Wrms x 2, <0.1% THD+N
Power Output, 2Ω: 120Wrms x 2, <0.1% THD+N
Power Output, 4Ω Bridged: 240Wrms x 1, <0.3% THD+N
Signal-to-Noise Ratio: >75dB (ref 1W output @ 4Ω)
Bluetooth® Audio Streaming
Clari-fi™ Music Restoration Technology
Party Mode allows sharing of streaming content
Cabin Controls and Telephone Integration
High Efficiency, Low Distortion Class D Design
GTR-104
High Performance 4-Channel Full Range Car Audio Power Amplifier
Max Power: 1500W Peak
Power Output, 4Ω: 100Wrms x 4, <0.1% THD+N
Power Output, 2Ω: 120Wrms x 4, <0.1% THD+N
Power Output, 4Ω Bridged: 240Wrms x 2, <0.3% THD+N
Signal-to-Noise Ratio: >75dB (ref 1 W output @ 4Ω)
Bluetooth® Audio Streaming
Clari-fi™ Music Restoration Technology
Party Mode allows sharing of streaming content
Cabin Controls and Telephone Integration
High Efficiency, Low Distortion Class D Design
GTR-601
High Performance Mono Car Audio Subwoofer Amplifier
Max Power: 1500W Peak
Power Output, 2Ω: 600Wrms x 1, <0.1% THD+N
Power Output, 4Ω: 380Wrms x 1, <0.1% THD+N
Signal-to-Noise Ratio: >80dB (ref 1W output @ 2Ω)
High-Efficiency, Low Distortion Class D Design
Noise-Rejecting Differential Inputs
Active LPF, variable 32 – 320Hz
Variable Line-Level and Speaker-Level Inputs (0.2 to 20V input range)
GTR-1001
High Performance Mono Car Audio Subwoofer Amplifier
Max Power: 2600W Peak
Power Output, 2Ω: 1000Wrms x 1, <0.1% THD+N
Power Output, 4Ω: 700Wrms x 1, <0.1% THD+N
Signal-to-Noise Ratio: >80dB (ref 1W output @ 2Ω)
High-Efficiency, Low Distortion Class D Design
Noise-Rejecting Differential Inputs
Active LPF, variable 32 – 320Hz
Variable Line-Level and Speaker-Level Inputs (0.2 to 20V input range)
GTR-7535
High Performance 5-Channel Car Audio System Amplifier
Max Power: 2300W Peak
Full Range Channels
Power Output, 4Ω: 75Wrms x 4, <0.1% THD+N
Power Output, 2Ω: 100Wrms x 4, <0.1% THD+N
Power Output, 4Ω Bridged: 200Wrms x 2, <0.3% THD+N
Signal-to-Noise Ratio: >75dB (ref 1W output @ 4Ω)
Subwoofer Channel
Power Output, 2Ω: 350Wrms x 1, <0.1% THD+N
Power Output, 4Ω: 200Wrms x 1, <0.1% THD+N
Signal-to-Noise Ratio: >80dB (ref 1W output @ 2Ω)
Bluetooth® Audio Streaming
Clari-fi™ Music Restoration Technology
Party Mode allows sharing of streaming content
Cabin Controls and Telephone Integration
High Efficiency, Low Distortion Class D Design
Infinity Reference Amplifier 3004A
AMP3004A
Features
Compact size
High and low level input
Variable crossover
Low noise and distortion
Input Level Control
Full on-board protection
Preamp Outputs
Class H amp technology
Turn-on mode
What’s in the Box:
One Reference 3004A four channel amplifier
4 Bare wire-to-RCA adapters
Four 30A ATO fuses (2 installed, 2 spare)
Owner's Manual
4 Mounting screws (M4 x 53mm)
2 Infinity decals
1 logo badage
Specifications:
4 channel car amplifier
75 watts RMS x 4 at 4 ohms(100 watts RMS x 4 at 2 ohms)
200 watts RMS x 2 at 4 ohms in bridged mode(4-ohm stable in bridged mode)
Variable high- and low-pass filters (32–320Hz,12dB/octave) on front and rear channels
Preamp and speaker-level inputs
Preamp outputs
Fuse rating: 30A x 2
8-gauge power and ground leads recommended –wiring and hardware not included with amplifier
W x H x D = 320mm x 55.5mm x 180mm
W x H x D = 12-5/8" x 2-3/16" x 7-1/8"
JBL Amplifiers GTR-104
GTR-104
Product specifications:
GTR-102
High Performance 2-Channel Full Range Car Audio Power Amplifier
Max Power: 700W Peak
Power Output, 4Ω: 100Wrms x 2, <0.1% THD+N
Power Output, 2Ω: 120Wrms x 2, <0.1% THD+N
Power Output, 4Ω Bridged: 240Wrms x 1, <0.3% THD+N
Signal-to-Noise Ratio: >75dB (ref 1W output @ 4Ω)
Bluetooth® Audio Streaming
Clari-fi™ Music Restoration Technology
Party Mode allows sharing of streaming content
Cabin Controls and Telephone Integration
High Efficiency, Low Distortion Class D Design
GTR-104
High Performance 4-Channel Full Range Car Audio Power Amplifier
Max Power: 1500W Peak
Power Output, 4Ω: 100Wrms x 4, <0.1% THD+N
Power Output, 2Ω: 120Wrms x 4, <0.1% THD+N
Power Output, 4Ω Bridged: 240Wrms x 2, <0.3% THD+N
Signal-to-Noise Ratio: >75dB (ref 1 W output @ 4Ω)
Bluetooth® Audio Streaming
Clari-fi™ Music Restoration Technology
Party Mode allows sharing of streaming content
Cabin Controls and Telephone Integration
High Efficiency, Low Distortion Class D Design
GTR-601
High Performance Mono Car Audio Subwoofer Amplifier
Max Power: 1500W Peak
Power Output, 2Ω: 600Wrms x 1, <0.1% THD+N
Power Output, 4Ω: 380Wrms x 1, <0.1% THD+N
Signal-to-Noise Ratio: >80dB (ref 1W output @ 2Ω)
High-Efficiency, Low Distortion Class D Design
Noise-Rejecting Differential Inputs
Active LPF, variable 32 – 320Hz
Variable Line-Level and Speaker-Level Inputs (0.2 to 20V input range)
GTR-1001
High Performance Mono Car Audio Subwoofer Amplifier
Max Power: 2600W Peak
Power Output, 2Ω: 1000Wrms x 1, <0.1% THD+N
Power Output, 4Ω: 700Wrms x 1, <0.1% THD+N
Signal-to-Noise Ratio: >80dB (ref 1W output @ 2Ω)
High-Efficiency, Low Distortion Class D Design
Noise-Rejecting Differential Inputs
Active LPF, variable 32 – 320Hz
Variable Line-Level and Speaker-Level Inputs (0.2 to 20V input range)
GTR-7535
High Performance 5-Channel Car Audio System Amplifier
Max Power: 2300W Peak
Full Range Channels
Power Output, 4Ω: 75Wrms x 4, <0.1% THD+N
Power Output, 2Ω: 100Wrms x 4, <0.1% THD+N
Power Output, 4Ω Bridged: 200Wrms x 2, <0.3% THD+N
Signal-to-Noise Ratio: >75dB (ref 1W output @ 4Ω)
Subwoofer Channel
Power Output, 2Ω: 350Wrms x 1, <0.1% THD+N
Power Output, 4Ω: 200Wrms x 1, <0.1% THD+N
Signal-to-Noise Ratio: >80dB (ref 1W output @ 2Ω)
Bluetooth® Audio Streaming
Clari-fi™ Music Restoration Technology
Party Mode allows sharing of streaming content
Cabin Controls and Telephone Integration
High Efficiency, Low Distortion Class D Design
High performance 4 channel car amplifier CLUBA754
CLUBA754
What’s in the box:
One Club A754 four channel amplifier
4 Bare wire-to-RCA adapters
Four 30A ATO fuses (2 installed, 2 spare)
Two JBL stickers
Owner’s Manual
4 Mounting screws (M4 x 53mm)
1 logo badage
Technical specifications:
4 channel car amplifier
75 watts RMS x 4 at 4 ohms
(100 watts RMS x 4 at 2 ohms)
200 watts RMS x 2 at 4 ohms in bridged
mode (4-ohm stable in bridged mode)
Variable high- and low-pass filters
(32–320Hz, 12dB/octave) on front and
rear channels
Preamp and speaker-level inputs
Preamp outputs
Fuse rating: 30A x 2
8-gauge power and ground leads
recommended – wiring and hardware not
included with amplifier
W x H x D = 320mm x 51.3mm x 180mm
W x H x D = 12-5/8" x 2-1/16" x 7-1/8"
JBL Amplifiers GX A604
GX-A604
Features
Cast-aluminum heat sink
Built-in electronic crossover networks
Bass boost circuits
What’s in the box:
1 GX-A604 amplifier
1 Owner’s manual
.png)
JBL Stage Amplifiers A6004
AMP-A6004
Features
Value Engineered
Compact footprint
Full On-Board Protection
Reliability
Input Level Control
Switchable bass EQ
Cool industrial design
Crossover mode switch
Crossover control gives user additional
fine tuning
Our Point of View
What’s in the Box
Amplifier
Spare Fuse (x2 for 1-channel and 4-channel model)
Quick start guide
High-level input cable (x2 for 4-channel model)
2x two-color JBL Brand Stickers
Mounting hardware
Mounting screws
Technical Specifications:
Stage A6002
| Power Output: | 90W x 2@2ohms; 60W x 2@4ohms; 180W x 1 bridged power@4ohms 9 – 16V 500W 20Hz – 20kHz @ -1dB |
| Operating voltage Total peak power Frequency response THD + N at rated power (20Hz – 20kHz) Line-in signal-to-noise ratio (reference to 1 watt) Maximum high input signal level High input maximum sensitivity Maximum line input signal level Line input maximum sensitivity Quiescent current draw Fuse size Dimensions (H x W x D) Weight |
|
| <1% | |
| >75dB 12V 0.5V 5V 0.2V <1.0A 20A 95 x 230 x 190mm 1.16kg |
Stage A6004
| Power Output: | 85W x 4@2ohms; 60W x 4@4ohms ; 170W x 2 bridged power@4ohms 9 – 16V 1000W 20Hz – 20kHz @ -1dB |
| Operating voltage Total peak power Frequency response THD + N at rated power (20Hz – 20kHz) Line-in signal-to-noise ratio (reference to 1 watt) Maximum high input signal level High input maximum sensitivity Maximum line input signal level Line input maximum sensitivity Quiescent current draw Fuse size Dimensions (H x W x D) Weight |
|
| <1% | |
| >75dB 12V 0.5V 5V 0.2V <1.2A 2 x 15A 95 x 260 x 190mm 1.381kg |
Stage A9004
Power Output: 110W x 4@2ohms;
90W x 4@4ohms;
220W x 2 bridged power@4 ohms
Operating voltage 9 – 16V
Total peak power 1200W
Frequency response 20Hz – 20kHz @ -1dB
THD + N at rated power
(20Hz – 20kHz) <1%
Line-in signal-to-noise ratio
(reference to 1 watt) >75dB
Maximum high input signal level 12V
High input maximum sensitivity 0.5V
Maximum line input signal level 5V
Line input maximum sensitivity 0.2V
Quiescent current draw <1.5A
Fuse size 2 x 20A
Dimensions (H x W x D) 95 x 325 x 190mm
Weight 1.806kg
Stage A3001
Power Output: 300W x 1@2ohms;
180W x 1@4ohms
Operating voltage 9 – 16V
Total peak power 600W
Frequency response 10Hz – 320kHz @ -3dB
THD + N at rated power
(20Hz – 20kHz) <1%
Line-in signal-to-noise ratio
(reference to 1 watt) >75dB
Maximum high input signal level 12V
High input maximum sensitivity 0.5V
Maximum line input signal level 5V
Line input maximum sensitivity 0.2V
Quiescent current draw <1.5A
Fuse size 2 x 15A
Dimensions (H x W x D) 95 x 313 x 190mm
Weight 1.609kg
